Mitsubishi GOT1000 Series - Connecting to FP10 SH

14 - 14
14.1 System Configuration
14.1.7 Connecting to FP10SH
14.1.7 Connecting to FP10SH
1 System configuration and connection conditions
2 System equipment
(1) GOT
(2) PLC
is a product manufactured by Matsushita Electric works, Ltd. For details of this product, contact Matsushita Electric
works, Ltd.
Connection conditions
System configuration
Number of
GOTs
Distance
1 15m or less
Image No. Name Model name
RS-232 interface
• For RS-232 communication
(Built into GOT)
RS-232 Communication Unit
• For RS-232 communication
GT15-RS2-9P
Image No. Name Model name
Computer communication unit AFP3462
MATSUSHITA
MEWNET-FP
Communication driver
Connect to the tool port
or RS232C port.
MAX15m
RS-232 cable 2)
3
1
MAX15m
Computer communication unit
2
RS-232 cable 2)
3
1
RS-232
RS-232
RS-232
