Mitsubishi GOT1000 Series - Attaching Communication Unit and Connecting Cable

3 - 28
3.3 Preparatory Procedure for Monitoring
3.3.5 Attaching communication unit and connecting cable
2 How to connect the cable
(1) How to connect the RS-232 cable
(a) For the GT15
• connection to the RS-232 interface
• connection to the RS-232 communication unit
(a) For the GT11
1 Connect the RS-232 cable to the RS-232
interface on the GOT.
1 Connect the RS-232 cable to the RS-232
communication unit on the GOT.
1 Connect the RS-232 cable to the RS-232
interface on the GOT.
