26.2 Preparatory Procedures for Monitoring
26.2.5 Attaching communication unit and connecting cable
26 - 9
25
BAR CODE READER
CONNECTION
26
PRINTER CONNECTION
27
CNC CONNECTION
28
MULTI-CHANNEL
FUNCTION
29
FA TRANSPARENT
FUNCTION
30
MULTIPLE-GT11
CONNECTION FUNCTION
31
GATEWAY FUNCTION INDEX
26.2.5 Attaching communication unit and connecting cable
Cautions when attaching the communication unit and connecting the cable
Shut off all phases of the GOT power supply before attaching the communication
unit and connecting the cable.
1 Attaching the communication unit
Printer unit
For details on the printer unitt, refer to the following manual:
GT15 Printer unit User's Manual
1 Connect the cable (packed together with the
printer unit) to the printer unit.
2 Attach the printer unit to the extension unit
connector on the GOT.
printer unit
cable
(packed together with
the printer unit)
To Next Page
