27.2 MELSECNET/10 Connection (PLC To PLC Network)

27.2.7 Attaching communication unit and connecting cable

Precautions for soldering

Note the following precautions when soldering the internal conductor and contact.

• Make sure that the solder does not bead up at the soldered section.

• Make sure there are no gaps between the connector and cable insulator or

they do not cut into each other.

• Perform soldering quickly so the insulation material does not become

deformed.

5 Insert the connector assembly shown in into the

plug shell and screw the nut into the plug shell.
