27.4 Ethernet Connection
27.4.1 System Configuration
27 - 63
25
BAR CODE READER
CONNECTION
26
PRINTER CONNECTION
27
CNC CONNECTION
28
MULTI-CHANNEL
FUNCTION
29
FA TRANSPARENT
FUNCTION
30
MULTIPLE-GT11
CONNECTION FUNCTION
31
GATEWAY FUNCTION INDEX
(2) CNC
*1 For the system configuration of the Ethernet module, refer to the following manuals.
MELDAS C6/C64 CONNECTION AND MAINTENANCE MANUAL BNP-B2255
MELDAS C6/C64 NETWORK MANUAL BNP-B2373
*2 Select one of the following [Type] in [Ethernet setting] of GT Designer2.
For [Ethernet setting] of GT Designer2, refer to the following.
Section 27.4.5 Setting communication interface (Communication settings)
(3) Cable
Image No. Name Model name
Expansion unit FUC6-EX875
Image No. Name Model name
Twisted pair cable
Shielded twisted pair cable (STP) or unshielded twisted pair cable in category
(UTP): 3, 4 and 5
