29.2 System Configuration
29.2.1 GX Developer
2 System equipment
(1) GOT
(2) PC
(3) Cable
System configuration between GOT and Mitsubishi PLC
For details on the system configuration between a GOT and a Mitsubishi PLC, refer
to the following.
Chapter 2 BUS CONNECTION
Chapter 3 DIRECT CONNECTION TO CPU
Image No. Name Model name
RS-232 interface
• For RS-232 communication
(Built into GOT)
USB interface
• For USB communication
(Built into GOT)
Image No. Name Model name
PC
For compatible software refer to the following.
( Section 29.3 Compatible Software)
Image No Name Model name
RS-232 cable GT01-C30R2-9S(3m)
USB cable GT09-C20USB-5P(2m)
RS-232
USB
To Next Page
