29.4 Preparatory Procedure for Accessing
29.4.5 Accessing the inverter by the FR Configurator
29 - 19
25
BAR CODE READER
CONNECTION
26
PRINTER CONNECTION
27
CNC CONNECTION
28
MULTI-CHANNEL
FUNCTION
29
FA TRANSPARENT
FUNCTION
30
MULTIPLE-GT11
CONNECTION FUNCTION
31
GATEWAY FUNCTION INDEX
2 When connecting the GOT and PC with USB
The following shows an access example by MT Developer (when connected to the FREQROL A700/F700
Series) when the GOT and PC are connected by USB
1 Click [Settings] [Communication
Settings...] in FR Configurator.
2 On the [Communication Port], mark the
[USB] checkbox.
3 Click the [GOT Transparent
Communication].
4 Click the [OK].
5 Click [OFFLINE] to make it [ONLINE].
6 Click the [System Read], then check if
GOT has been connected to FREQROL
A700/F700 series normally.
To Next Page
