Select a system configuration suitable for your application.
(1) Connectable network
Connect the GOT to the following network systems as an ordinary station.
• MELSECNET/10 network system (PLC to PLC network) optical loop system
• MELSECNET/10 network system (PLC to PLC network) coaxial bus system
(2) MELSECNET/H network module
When connecting the MELSECNET/H network module to the MELSECNET/10
network system, specify the MELSECNET/10 Mode as a network type.
(3) Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions
correspond to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
