6 - 10
6.2 Preparatory Procedures for Monitoring
6.2.3 Setting communication interface (Communication settings)
(4) Condition setting switches
(1) Switch setting example
For the switch setting example, refer to the following.
Section 6.3 PLC Side Setting
(2) When the switch setting is changed
When changing the switch setting after mounting the MELSECNET/10
communication unit to the GOT, reset the GOT.
Condition setting switches Setting switch Description Setting
SW1
Specify input data status of the data link error station.
<Default: OFF>
OFF: Cleared
ON: Held
SW2
Specify the number of stations occupied.
<Default: OFF>
OFF: 1 station
ON: 4 stations
21
ON
