8.2 Preparatory Procedures for Monitoring
8.2.3 Setting communication interface (Communication settings)
8 - 9
1
OVERVIEW
2
BUS CONNECTION
3
DIRECT CONNECTION
TO CPU
4
COMPUTER LINK
CONNECTION
5
MELSECNET/10
CONNECTION (PLC TO
PLC NETWORK)
6
CC-Link CONNECTION
(INTELLIGENT DEVICE
STATION)
7
CC-Link CONNECTION
(Via G4)
8
ETHERNET
CONNECTION
(from previous page)
*1 To connect the GOT with the Ethernet module (Q Series) in the one-on-one relationship using a cross cable, set
[Timeout Time] to 6 sec. or longer.
Example of communication detail settings
For examples of communication detail settings, refer to the following.
Section 8.3 PLC Side Setting
Item Description Range
Delay Time
Set the delay time for reducing the load of the network/destination
PLC.
<Default: 0ms>
0 to 10000 ( 10 ms)
To Next Page
