Page #328 background imageLoading...
Page #328 background image
8 - 24
8.3 PLC Side Setting
8.3.1 Connecting to Ethernet module (Q Series)
4 Confirming the communication state of Ethernet module
(1) When using the Command Prompt of Windows
Execute a Ping command at the Command Prompt of Windows .
(a) When normal communication
C:\>Ping 192.168.0.19
Reply from 192.168.0.19: bytes=32 time<1ms TTL=64
(b) When abnormal communication
C:\>Ping 192.168.0.19
Request timed out.
(2) When abnormal communication
At abnormal communication, check the followings and execute the Ping command again.
Mounting condition of Ethernet communication unit
Cable connecting condition
Confirmation of switch and network parameter setting
Operation state of PLC CPU (faulty or not)
IP address of GOT specified by Ping command
Ethernet diagnostics of GX Developer
Ethernet diagnostics of GX Developer is available to a Ping test from the PLC.
For details of Ethernet diagnostics of GX Developer, refer to the following manual.
User’s manual of the Ethernet module
