9 - 1

CONNECTION TO

OMRON PLC

CONNECTION TO

KEYENCE PLC

CONNECTION TO

SHARP PLC

CONNECTION TO

TOSHIBA PLC

CONNECTION TO

HITACHI PLC

CONNECTION TO

MATSUSHITA PLC

CONNECTION TO

YASKAWA PLC

CONNECTION TO

YOKOGAWA PLC

CONNECTION TO

OMRON PLC

9.1 System Configuration . . . . . . . . . . page 9-2

This section describes the equipment and cables needed

when connecting a GOT to an OMRON PLC.

Select a system suitable for your application.

9.2 Connection Cable . . . . . . . . . . . . page 9-17

This section describes the specifications of the cables

needed when connecting to an OMRON PLC.

Check the specifications of the connection cables.

9.3 Preparatory Procedures for Monitoring

. . . . . . . . . . . . . . . . . . . . . . . . . . page 9-23

This section provides the procedures to be followed before

performing monitoring in connection to an OMRON PLC.

This procedures are written on the step-by-step basis so

that even a novice GOT user can follow them to start

communications.

9.4 PLC Side Setting . . . . . . . . . . . . . page 9-37

The PLC side settings for GOT connection are explained.

When checking the PLC side settings, refer to this section.
