9 - 22

9.2 Connection Cable

9.2.2 RS-422 cable

2 Connector specifications

(1) GOT side connector

Use the following as the RS-422 interface and RS-422/485 communication unit connector on the

GOT.

For the GOT side of the RS-422 cable, use a connector and connector cover applicable to the GOT

connector.

(a) Connector type

9-pin D-sub (female)

(b) Connector model

(2) OMRON PLC side connector

Use the connector compatible with the OMRON PLC side module.

For details, refer to the following manual.

User's Manual for the OMRON PLC

3 Precautions when preparing a cable

The length of the RS-422 cable must be 200m or less.

4 Connecting the terminator

When connecting an OMRON PLC to a GOT, a terminating resistor must be set to the OMRON PLC.

No terminating resistor needs to be connected on the GOT side as one is already built into the GOT.

Section 9.4 PLC Side Setting

GOT Model Manufacturer

RS-422 conversion unit 17LE-13090-27(D2AC) DDK Ltd.

GT11 17LE-13090-27(D3AC) DDK Ltd.

GT15-RS4-9S 17LE-13090-27(D3AC) DDK Ltd.
