11.2 Connection Cable
11 - 15
9
CONNECTION TO OMRON PLC
10
CONNECTION TO KEYENCE PLC
11
CONNECTION TO SHARP PLC
12
CONNECTION TO TOSHIBA PLC
13
CONNECTION TO HITACHI PLC
14
CONNECTION TO MATSUSHITA PLC
15
CONNECTION TO YASKAWA PLC
16
CONNECTION TO YOKOGAWA PLC
11.2 Connection Cable
The RS-232 cable or RS-422 cable used for connecting the GOT to the PLC should be prepared by the user.
The following provides connection diagrams for each cable, connector specifications and other information.
Model name
Connection cable
RS-232 cable
(Refer to Section 11.2.1.)
RS-422 cable
(Refer to Section 11.2.2.)
PLC CPU
JW-22CU RS-232 cable 1) RS-422 cable 1)
JW-32CUH, JW-33CUH
Connecting to PG/COMM1
port
RS-422 cable 2)
Connecting to PG/COMM2
port
RS-232 cable 2)
JW-70CUH, JW-100CUH, JW-100CU RS-232 cable 1) RS-422 cable 1)
Z-512J
Connecting to PG/COMM1
port
RS-422 cable 2)
Connecting to PG/COMM2
port
RS-232 cable 2)
Link unit
JW-21CM
RS-422 cable 3)
JW-10CM, ZW-10CM

Mitsubishi GOT1000 Series Specifications

General

Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Series	GOT1000
Resolution	640 x 480 pixels
Touch Panel Type	Resistive
Interface	RS-232, USB
Storage Temperature	-20 to 60°C
Protection Rating	IP65
Display Type	TFT LCD
Brightness	400 cd/m²
Backlight Life	50, 000 hours
CPU	RISC
Shock Resistance	147 m/s²
Display Size	10.4 inches
