Mitsubishi GOT1000 Series - Page 473

11.4 PLC Side Setting
11.4.3 Connecting to the link unit (JW-31CM)
11 - 39
9
CONNECTION TO OMRON PLC
10
CONNECTION TO KEYENCE PLC
11
CONNECTION TO SHARP PLC
12
CONNECTION TO TOSHIBA PLC
13
CONNECTION TO HITACHI PLC
14
CONNECTION TO MATSUSHITA PLC
15
CONNECTION TO YASKAWA PLC
16
CONNECTION TO YOKOGAWA PLC
(5) Transmission speed setting switch (SW4)
Specify the transmission speed to match the transmission speed of the GOT.
For how to set the transmission speed of the GOT, refer to the following.
Section 11.3.3 Setting communication interface (Communication settings)
(6) Function setting switch(SW0)
Setting*
1
Description
0 19200bps
1 9600bps
2 4800bps
*1 Indicates only the transmission speed that can be specified on the GOT side.
Setting Description
4 (fixed) Computer link
SW4
C
B
A
9
8
7
6
5
F
E
D
4
3
2
1
0
SW0
C
B
A
9
8
7
6
5
F
E
D
4
3
2
1
0
