11.4 PLC Side Setting
11.4.4 Connecting to the link unit (JW-10CM or ZW-10CM)
11 - 41
9
CONNECTION TO
OMRON PLC
10
CONNECTION TO
KEYENCE PLC
11
CONNECTION TO
SHARP PLC
12
CONNECTION TO
TOSHIBA PLC
13
CONNECTION TO
HITACHI PLC
14
CONNECTION TO
MATSUSHITA PLC
15
CONNECTION TO
YASKAWA PLC
16
CONNECTION TO
YOKOGAWA PLC
(4) Transmission speed setting switch (SW4)
Specify the transmission speed to match the transmission speed of the GOT.
For how to set the transmission speed of the GOT, refer to the following.
Section 11.3.3 Setting communication interface (Communication settings)
(5) Terminator switch(SW7)
Setting*
1
Description
0 19200bps
1 9600bps
2 4800bps
*1 This indicates only the transmission speed that can be specified on the GOT side.
Setting Description
ON
*2
Terminating resistor
*2 Set to ON only for the terminal station.
3
2
0
5
9
4
8
7
6
1
SW4
SW7
ON
OFF
To Next Page
