12 - 6
12.1 System Configuration
12.1.2 Connecting to model 3000 (S2/S3)
(2) Cable
*1 The RS-232 cable can be prepared by the user. ( Section 12.2 Connection Cable)
Image No. Name Model name
RS-422 cable 2)
• Between CPU and GOT
GT09-C30R40502-6C(3m)
GT09-C100R40502-6C(10m)
GT09-C200R40502-6C(20m)
GT09-C300R40502-6C(30m)
RS-422 cable 1)
• Between CPU and GOT
GT09-C30R40501-15P(3m)
GT09-C100R40501-15P(10m)
GT09-C200R40501-15P(20m)
GT09-C300R40501-15P(30m)
