15.3 Preparatory Procedure for Monitoring
15.3.5 Attaching communication unit and connecting cable
15 - 27
9
CONNECTION TO
OMRON PLC
10
CONNECTION TO
KEYENCE PLC
11
CONNECTION TO
SHARP PLC
12
CONNECTION TO
TOSHIBA PLC
13
CONNECTION TO
HITACHI PLC
14
CONNECTION TO
MATSUHSHITA PLC
15
CONNECTION TO
YASKAWAI PLC
16
CONNECTION TO
YOKOGAWA PLC
(2) How to connect the RS-422 cable
(a) For the GT15
• connection to the RS-232 interface
• connection to the RS-422/485 communication unit
RS-422 conversion unit
For details of the RS-422 conversion unit, refer to the following manual.
GT15 RS-422 Conversion Unit User's Manual
1 Connect the RS-422 conversion unit to the RS-
232 interface on the GOT.
2 Connect the RS-422 cable to the RS-422
conversion unit.
1 Connect the RS-232 cable to the RS-232
communication unit on the GOT.
To Next Page
