15.4 PLC Side Setting
YASKAWA PLC
For details of YASKAWA PLCs, refer to the following manuals.
Manuals for YASKAWA PLCs
1 Communication and port settings
Make the communication and port settings with a peripheral tool.
*1 Set the address according to the Host Address setting on the GOT side.
For the Host Address setting on the GOT side, refer to the following.
Section 15.3.3 Setting communication interface (Communication settings)
*2 Only transmission speeds available on the GOT side are shown.
Also, the setting range differs depending on the YASKAWA PLC model.
*3 Set the same transmission speed as that of the GOT side.
For the transmission speed setting on the GOT side, refer to the following.
Section 15.3.3 Setting communication interface (Communication settings)
Device Name Settings
Address
*1
1 to 31
Protocol MEMOBUS
Mode RTU
Transmission speed
*2*3
4800bps, 9600bps, 19200bps, 38400bps, 57600bps
Data length 8 bits
Stop bit 1 bit
Parity bit Even
Error check CRC16
