16.2 Connection Cable
16.2.2 RS-422 cable
16 - 11
9
CONNECTION TO OMRON PLC
10
CONNECTION TO KEYENCE PLC
11
CONNECTION TO SHARP PLC
12
CONNECTION TO TOSHIBA PLC
13
CONNECTION TO HITACHI PLC
14
CONNECTION TO MATSUHSHITA PLC
15
CONNECTION TO YASKAWA PLC
16
CONNECTION TO YOKOGAWA PLC
16.2.2 RS-422 cable
The following shows the connection diagrams and connector specifications of the RS-422 cable used for
connecting the GOT to a PLC.
Differences in polarity between GOT and YOKOGAWA products
The polarity of poles A and B in signal names is reversed between GOT and
YOKOGAWA products.
Connect a cable according to the following connection diagrams.
1 Connection diagram
(1) RS-422 cable 1)
(2) RS-422 cable 2)
GOT side
Cable connection and signal direction
YOKOGAWA product side
Signal name Pin No. Terminal block name
RDA 2 SDB
RDB 7 SDA
SDA 1 RDB
SDB 6 RDA
RSA 3
RSB 8
CSA 4
CSB 9
SG 5 SG
FG SHIELD
GOT side
Cable connection and signal direction
YOKOGAWA product side
Signal name Pin No. Terminal block name
RDA 2 SDB
RDB 7 SDA
SDA 1 RDB
SDB 6 RDA
RSA 3
RSB 8
CSA 4
CSB 9
SG 5 SG
FG FG
R
R

Mitsubishi GOT1000 Series Specifications

General

Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Series	GOT1000
Resolution	640 x 480 pixels
Touch Panel Type	Resistive
Interface	RS-232, USB
Storage Temperature	-20 to 60°C
Protection Rating	IP65
Display Type	TFT LCD
Brightness	400 cd/m²
Backlight Life	50, 000 hours
CPU	RISC
Shock Resistance	147 m/s²
Display Size	10.4 inches
