2.1 System Configuration
2.1.3 Connecting to QnASCPU or AnSCPU type
(2) When using the extension base unit
(Continued to next page)
*1 This includes the extension cable length (between the base unit and the extension base unit).
*2 The number of connectable GOTs is limited by the type of the connected CPU and the number of the intelligent
function modules.
Section 2.3 When connecting multiple GOTs
Connection conditions
System configuration
Number of
GOTs
*2
Distance from main
base unit to 1st GOT
1
6m or less
More than 6m
Connection cable
(a)+(b)=MAX6m
*1
4
(a)
(b)
1
Connection cable
(b)=MAX30m
(a)+(b)=MAX36m
*1
5
(a)
(b)
1
(a)+(b)=MAX6m
*1
Connection
cable
6
Connection cable
5
(a)
(b)
Bus connector conversion box
3
(a)+(b)+(c)=MAX36m
*1
(c)
1
