17.4 PLC Side Setting
17.3.7 Checking for normal monitoring
17 - 23
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
Allen-Bradley PLC
For details of Allen-Bradley PLCs, refer to the following manuals.
Manuals for Allen-Bradley PLCs
1 Direct CPU connection (setting of Allen-Bradley PLC)
*1 Set the Baud Rate according to the transmission speed setting on the GOT side.
For the transmission speed setting on the GOT side, refer to the following.
Section 17.3.3 Setting communication interface (Communication settings)
*2 Set the Error Detection according to the sum check format setting on the GOT side.
For the sum check format setting on the GOT side, refer to the following.
Section 17.3.3 Setting communication interface (Communication settings)
Item
Setting details
SLC500 Series MicroLogix1000/1200/1500 Series
Baud Rate
*1
4800bps, 9600bps, 19200bps 4800bps, 9600bps, 19200bps, 38400bps
Parity EVEN NONE
Control Line NO HANDSHAKING
Communication Driver DF1 HALF-DUPLEX SLAVE
Duplicate Packet Detection DISABLE
Station Address 0
Error Detection BCC
BCC, CRC
*2

Mitsubishi GOT1000 Series Specifications

General

Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Series	GOT1000
Resolution	640 x 480 pixels
Touch Panel Type	Resistive
Interface	RS-232, USB
Storage Temperature	-20 to 60°C
Protection Rating	IP65
Display Type	TFT LCD
Brightness	400 cd/m²
Backlight Life	50, 000 hours
CPU	RISC
Shock Resistance	147 m/s²
Display Size	10.4 inches
