MICROCOMPUTER
CONNECTION
19.1 Microcomputer Connection . . . . . page 19-2
This section describes the microcomputer connection of
the GOT.
19.2 System Configuration . . . . . . . . . page 19-4
This section describes the equipment and cables needed
for establishing a microcomputer connection.
Select a system suitable for your application.
19.3 Connection Cable . . . . . . . . . . . . page 19-7
This section describes the specifications of the cables
needed when connecting a GOT to a microcomputer.
Check the specifications of the connection cables.
19.4 Device Data Area . . . . . . . . . . . page 19-10
This section describes the virtual devices on the GOT,
which are used for data transactions when a
microcomputer connection is established.
19.5 Message Formats . . . . . . . . . . . page 19-23
This section describes the message formats used in the
microcomputer connection.
19.6 Preparatory Procedures for Monitoring . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . page 19-73
This section provides the procedures to be followed before
performing monitoring in a microcomputer connection.
The procedures are written on the step-by-step basis so
that even a novice GOT user can follow them to start
communications.
19.7 System Configuration Examples .page 19-87
This section gives an example of a system configuration for
the microcomputer connection.
