Mitsubishi GOT1000 Series - Page 738

19 - 8
19.3 Connection Cable
19.3.1 RS-232 cable
2 Connector specifications
(1) GOT side connector
Use the following as the RS-232 interface and RS-232 communication unit connector on the GOT.
For the GOT side of the RS-232 cable, use a connector or connector cover applicable to the GOT
connector.
(a) Connector type
9-pin D-sub (male) inch screw fixed type
(b) Connector model
*1 For the confirmation method of GT15 hardware version, refer to the following manual.
GT15 User's Manual
(2) Host side connector
Use the connector compatible with the host side.
3 Precautions when preparing a cable
The length of the RS-232 cable must be 15m or less.
GOT
Hardware
version*1
Model Manufacturer
GT1595-X A 17LE-23090-27(D3CC) DDK Ltd.
GT1585-S
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B 17LE-23090-27(D3CC) DDK Ltd.
GT1575-S
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B 17LE-23090-27(D3CC) DDK Ltd.
GT1575-V
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B
17LE-23090-27(D3CC) DDK Ltd.
GT1575-VN
A
GT1572-VN
GT1565-V
GT1562-VN
GT11
GT15-RS2-9P
