*1 If a wrong day of the week is set by the clock data setting command, the clock data will differ from the time
displayed on the utility.
Example: When June 1, 2004 (Thursday) is set by the clock data setting command (the actual day of week is
Tuesday),"04" is stored to D9 although Tuesday (TUE) will be displayed on the utility time display.
About the side where virtual devices are set
System: Set on the system side.
User: Set on the user side (by sending request messages from host or
using the touch switches, etc. on the GOT).
2 Details and actions for errors (error codes) stored into SD2
Address Description Set side
SD8
Clock data (year)
4-digit year data is stored.
System
SD9
Clock data (day of week)
*1
Day-of-the-week data is stored.
0: Sunday 1: Monday 2: Tuesday 3: Wednesday
4: Thursday 5: Friday 6: Saturday
SD10 to 15 Unused
Error code Description Action
0No error
1,101
Parity error
The parity bit is not correct.
• Check the communication cable and communication unit
for correct connection.
• Check the Communication Detail Settings.
• Set the same transmission settings on the GOT and the
host.
2,102
Framing error
The data bit and/or stop bit are not correct.
3,103
Overrun error
The next data were transmitted from the host before
completion of the received data processing on the GOT.
• Check the Communication Detail Settings.
• Decrease the transmission speed.
4,104
Communication message error
EXT/CR could not be found before the upper limit of the
receive buffer was exceeded.
• Check the communication cable and communication unit
for correct connection.
• Check the Communication Detail Settings.
• Review the contents of the sending message
5
Command error
An unsupported command was used.
• Review the contents of the sending message.
• Check the command in the message.
( Section 19.5.2 List of commands)
105
Timeout error
There is no response from the GOT, or the station of the
specified address does not exist.
• Check the communication cable and communication unit
for correct connection.
• Check the Communication Detail Settings.
• Review the contents of the sending message.
106
Multiple units not connectable
The RS-232 port is occupied.
• Check the communication cable and communication unit
for correct connection.
• Check the Communication Detail Settings.
• Check to see if the RS-232 port is occupied.
6,107
Clock data setting error
A wrong value is set in the clock data.
• Review the contents of the sending message.
• Check if any invalid data (e.g. "07" set as a day of the
week) is set as clock data.
