19 - 24
19.5 Message Formats
19.5.1 Data format type and application
(4) Formats 11 to 13 (Digital Electronics Corporation's memory link method)
This is the same format as the protocol of the Digital Electronics Corporation's memory link
method.
(5) Formats 14, 15 (GOT-F900 series microcomputer connection)
This is the same message format as when a microcomputer connection is established with the
GOT-F900 Series.
2 How to set data format
Set the data format at "Communication Detail Settings" in GT Designer2.
For details of the data format setting method, refer to the following.
Section 19.6.3 Setting communication interface (Communication settings)
Type Name Description Reference
Format 11
Digital Electronics Corporation's memory link
method (compatible mode)
This is the basic format of the Digital Electronics Corporation's
memory link method.
Section
19.5.6
Format 12
Digital Electronics Corporation's memory link
method (extended mode, ASCII code 1:1)
This is the appended format of the Digital Electronics Corporation's
memory link method (compatible mode) with sum check, CR and LF.
Format 13
Digital Electronics Corporation's memory link
method (extended mode, ASCII code 1:n)
This is the appended format of the Digital Electronics Corporation's
memory link method (extended mode, ASCII code 1:1) with a station
No.
Type Name Description Reference
Format 14
GOT-F900 series microcomputer connection
(format 1)
Use this format when establishing a 1:1 or m:n connection between
the GOT and the host.
The end code is CR.
Section
19.5.7
Format 15
GOT-F900 series microcomputer connection
(format 2)
Use this format when establishing a 1:1 or m:n connection between
the GOT and the host.
The end code is ETX or sum check.
To Next Page
