19.5 Message Formats
19.5.2 List of commands
19 - 27
17
CONNECTION TO
ALLEN-BRADLEY PLC
18
CONNECTION TO
SIEMENS PLC
19
MICROCOMPUTER
CONNECTION
20
CONNECTION TO OMRON
TEMPERATURE
CONTROLLER
21
CONNECTION TO
YAMATAKE TEMPERATURE
CONTROLLER
22
CONNECTION TO RKC
TEMPERATURE
CONTROLLER
23
CONNECTION TO
FREQROL SERIES
INVERTER
24
SERVO AMPLIFIER
CONNECTION
5 List of commands for formats 14, 15 (GOT-F900 series microcomputer connection)
Command
Command name Description
Max. number of points
processed
Symbol
ASCII
code
030H
Batch read
(w/out station No.)
Reads bit devices in byte units. 255bytes (2040 points)
Reads word devices in byte units. 255bytes (127 points)
A41H
Batch read
(w/ station No.)
Reads bit devices in byte units. 255bytes (2040 points)
Reads word devices in byte units. 255bytes (127 points)
131H
Batch write
(w/out station No.)
Writes to bit devices in byte units. 255bytes (2040 points)
Writes to word devices in byte units. 255bytes (127 points)
B42H
Batch write
(w/ station No.)
Writes to bit devices in byte units. 255bytes (2040 points)
Writes to word devices in byte units. 255bytes (127 points)
333H
Multi-point write in bit
units
(w/ station No.)
Writes bit patterns (bit ON/OFF, inversion, direct specification) in
1-point units (8 bits for 1 point) to a specified device.
70 bytes (560 points)
D44H
Multi-point write in bit
units
(w/ station No.)
434H
Fill command
(w/out station No.)
Writes the same value to a range of specified devices.
E45H
Fill command
(w/ station No.)
535H
Set clock data
(w/out station No.)
Sets the clock data of the GOT.
F46H
Set clock data
(w/ station No.)
636H
Read clock data
(w/out station No.)
Reads the clock data of the GOT.
G47H
Read clock data
(w/ station No.)
