Mitsubishi GOT1000 Series User Manual

19.5 Message Formats
19.5.7 Formats 14, 15 (GOT-F900 series microcomputer connection)
19 - 67
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
*2 The write specification specifies how the data of the specified address is changed in the bit pattern.
Write
specification
Function Description Action example
0
ON
specification
Bits set to "1" by the bit pattern are turned ON.
Original data 1010
Bit pattern 1100
Result 1110
1
OFF
specification
Bits set to "1" by the bit pattern are turned OFF.
Original data 1010
Bit pattern 1100
Result 0010
2
Invert
specification
Bits set to "1" by the bit pattern are inverted.
Original data 1010
Bit pattern 1100
Result 0110
3
Write
specification
The numerical values to write by the bit pattern are
specified directly.
Original data 1010
Bit pattern 1100
Result 1100

Mitsubishi GOT1000 Series Specifications

General

Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Series	GOT1000
Resolution	640 x 480 pixels
Touch Panel Type	Resistive
Interface	RS-232, USB
Storage Temperature	-20 to 60°C
Protection Rating	IP65
Display Type	TFT LCD
Brightness	400 cd/m²
Backlight Life	50, 000 hours
CPU	RISC
Shock Resistance	147 m/s²
Display Size	10.4 inches
