20.3 Preparatory Procedures for Monitoring
20.3.5 Attaching communication unit and connecting cable
20 - 23
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
(2) How to connect the RS-485 cable
1 Connect the RS-485 cable to the terminal block
packed together with the RS-422/485
communication unit.
2 Connect the terminal block to theRS-422/485
communication unit on the GOT.
