21 - 1
21
17
CONNECTION TO
ALLEN-BRADLEY PLC
18
CONNECTION TO
SIEMENS PLC
19
MICROCOMPUTER
CONNECTION
20
CONNECTION TO OMRON
TEMPERATURE
CONTROLLER
21
CONNECTION TO
YAMATAKE TEMPERATURE
CONTROLLER
22
CONNECTION TO RKC
TEMPERATURE
CONTROLLER
23
CONNECTION TO
FREQROL SERIES
INVERTER
24
SERVO AMPLIFIER
CONNECTION
CONNECTION TO
YAMATAKE
TEMPERATURE
CONTROLLER
21.1 System Configuration. . . . . . . . . . . page 21-2
This section describes the equipment and cables needed
when connecting a GOT to a YAMATAKE temperature
controller.
Select a system suitable for your application.
21.2 Connection Cable. . . . . . . . . . . . . page 21-18
This section describes the specifications of the cables needed
when connecting a GOT to a YAMATAKE temperature
controller.
Check the specifications of the connection cables.
21.3 Preparatory Procedures for Monitoring . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . page 21-24
This section provides the procedures to be followed before
performing monitoring in connection to a YAMATAKE
temperature controller.
The procedures are written on the step-by-step basis so that
even a novice GOT user can follow them to start
communications.
21.4 Temperature Controller Side Setting . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . page 21-38
The YAMATAKE temperature controller side settings for GOT
connection are explained.
When checking the PLC side settings, refer to this section.
21.5 Precautions . . . . . . . . . . . . . . . . . page 21-43
This section describes the precautions about temperature
controller connection.
Refer ti this section without fail before starting temperature
controller connection.
21.6 List of Functions Added by Version Upgrade .
. . . . . . . . . . . . . . . . . . . . . . . . . page 21-44
This section describes the functions added by version upgrade
of GT Designer2 or OS.
To Next Page
