21.1 System Configuration
21.1.2 Connecting to SDC15, SDC25/26 or SDC35/36
21 - 5
17
CONNECTION TO
ALLEN-BRADLEY PLC
18
CONNECTION TO
SIEMENS PLC
19
MICROCOMPUTER
CONNECTION
20
CONNECTION TO OMRON
TEMPERATURE
CONTROLLER
21
CONNECTION TO
YAMATAKE TEMPERATURE
CONTROLLER
22
CONNECTION TO RKC
TEMPERATURE
CONTROLLER
23
CONNECTION TO
FREQROL SERIES
INVERTER
24
SERVO AMPLIFIER
CONNECTION
2 System equipment
(1) GOT
(2) Temperature controller
is a product manufactured by YAMATAKE. For details of this product, contact YAMATAKE.
(3) Cable
Image No. Name Model name
RS-232 interface
• For RS-232 communication
(Built into GOT)
RS-232 Communication Unit
• For RS-232 communication
GT15-RS2-9P
RS-422/485 Communication Unit
• For RS-485 communication
GT15-RS4-TE
Image No. Name Model name
communication controller CMC10L
Image No. Name Model name
RS-232 cable 1)
Between interface converter
and GOT
(To be prepared by the user. Section 21.2 Connection Cable)j
RS-485 cable 1)
Between temperature controller
and interface converter
RS-485 cable 3)
Between temperature controller
and GOT
RS-232
RS-232
RS-422/485
