21.1 System Configuration
21.1.3 Connecting to SDC20/21
21 - 7
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
2 System equipment
(1) GOT
(2) Temperature controller
is a product manufactured by YAMATAKE. For details of this product, contact YAMATAKE.
Image No. Name Model name
RS-232 interface
• For RS-232 communication
(Built into GOT)
RS-232 Communication Unit
• For RS-232 communication
GT15-RS2-9P
RS-422 interface
• For RS-485 communication
(Built into GOT)
RS-422/485 Communication Unit
• For RS-485 communication
GT15-RS4-9S
RS-422/485 Communication Unit
• For RS-485 communication
GT15-RS4-TE
Image No. Name Model name
communication controller CMC10L
RS-232
RS-232
RS-232
RS-422
RS-422/485
RS-422/485
RS-422/485
RS-422/485
