21.1 System Configuration
21.1.5 Connecting to SDC40A/40B/40G
21 - 13
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
(3) Cable
Image No. Name Model name
RS-232 cable 2)
• Between temperature
controller and GOT
(To be prepared by the user. Section 21.2 Connection Cable)
RS-232 cable 1)
• Between interface
converter and GOT
RS-485 cable 2)
• Between temperature
controller and interface
converter
RS-485 cable 4)
• Between temperature
controller and GOT
RS-485 cable 5)
• Between temperature
controller and GOT
