Mitsubishi GOT1000 Series User Manual

23.1 System Configuration
23.1.2 Connecting to FREQROL E500/S500
23 - 5
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
23.1.2 Connecting to FREQROL E500/S500
1 System configuration and connection conditions
*1 Connect to the PU port of the inverter.
Connection conditions
System configuration
Number of
GOTs
Number of
inverters
Distance
1 1 500m or less
1 10 (max.) 500m or less
FREQROL 500/700
Communication driver
RS-422 cable 1)
3
MAX500m
1
*1
MAX500m
1
RS-422 cable 3)
4
RS-422 cable 1)
3
RS-422 cable 1)
2
2
*1
2
5
10 (max.)
Distributor
Distributor
Distributor
*1
*1

Mitsubishi GOT1000 Series Specifications

General

Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Series	GOT1000
Resolution	640 x 480 pixels
Touch Panel Type	Resistive
Interface	RS-232, USB
Storage Temperature	-20 to 60°C
Protection Rating	IP65
Display Type	TFT LCD
Brightness	400 cd/m²
Backlight Life	50, 000 hours
CPU	RISC
Shock Resistance	147 m/s²
Display Size	10.4 inches
