Monarch nice3000 - Page 172

NICE3000
new
User Manual
7 Function Code Table
- 171 -
7
Function
Code
Parameter Name Setting Range Default Unit Property Page
F5-13 X13 function selection
24/56: Door machine 1 light
curtain signal NO/NC
25/57: Door machine 2 light
curtain signal NO/NC
26/58: Brake travel switch 1 NO/
NC
27/59: Emergency evacuation
signal NO/NC
28/60: Elevator lock signal NO/NC
29/61: Safety circuit 2 feedback
NO/NC
30/62: Shorting PMSM stator
feedback NO/NC
31/63: Door lock circuit 2
feedback NO/NC
32/64: Reserved
65/97: Door machine 1 safety
edge signal NO/NC
66/98: Door machine 2 safety
edge signal NO/NC
67/99: Motor overheat signal NO/
NC
68/100: Earthquake signal NO/NC
69/101: Back door forbidden
signal NO/NC
70/102: Light-load signal NO/NC
71/103: Half-load signal NO/NC
72/104: Fire emergency oor
switchover signal NO/NC
76/108: Door 1 open input NO/NC
77/109: Door 2 open input NO/NC
78/110: Brake travel switch 2
input NO/NC
(End)
45 -
★
204
F5-14 X14 function selection 48 -
★
204
F5-15 X15 function selection 49 -
★
204
F5-16 X16 function selection 50 -
★
204
F5-17 X17 function selection 51 -
★
204
F5-18 X18 function selection 00 -
★
204
F5-19 X19 function selection 00 -
★
204
F5-20 X20 function selection 00 -
★
204
F5-21 X21 function selection 00 -
★
204
F5-22 X22 function selection 00 -
★
204
F5-23 X23 function selection 00 -
★
204
F5-24 X24 function selection 00 -
★
204
F5-25 CTB input type 0–511 320 -
★
209
