3 Mechanical and Electrical Installation NICE3000
new
User Manual
- 30 -
3
2) Sheet metal structure, 18.5–30 kW, Size-E
W
A
φ
B
H
D
3) Sheet metal structure, 37–55 kW, Size-F
W
A
B
H
D
φ
Table 3-1 Mounting dimensions of the NICE3000
new
Controller Model
Physical Dimensions Mounting Hole
Hole Diameter
(mm)
Gross
Weight
(kg)
Size
H (mm) W (mm) D (mm) A (mm) B (mm) Ф (mm)
Single/Three-phase 220 V, range: 200−240 V
NICE-L-C-2002
347 223 143 150 334.5 6.5 5.5 SIZE-C
NICE-L-C-2003
220-NICE-L-C-4007
347 223 172.5 150 334.5 6.5 7 SIZE-D220-NICE-L-C-4011
220-NICE-L-C-4015
220-NICE-L-C-4018
554.5 289.6 207.7 235 541.5 6.5 14.5 SIZE-E220-NICE-L-C-4022
220-NICE-L-C-4030
