• Perform rough adjustment first when the degree of misalignment is difficult to determine.
3. Print out the confirmation pattern again and check if the printer has been adjusted properly.
3.7.2.1 Custom confirmation pattern
4. If it has not been adjusted yet, return to Step 2.
• Perform micro adjustment if the printer is not fully adjusted after rough adjustment.
• In micro adjustment patterns, there are Adjust pattern ALL where all patterns will be adjusted and
Individual Adj. pattern where the patterns A to D can be adjusted individually.
3.7.2.3.1 Adj. Pattern ALL
3.7.2.3.2 Individual Adj. pattern
3.7.2.1 Custom confirmation pattern
Using this menu, you can print out all of the confirmation patterns (A to D) and check the degree of
misalignment.
1. Turn ON the printer and load the roll media.
3.5.4 Loading roll media
2. Display the Adjust Print menu on Operation panel.
a. Press the [Menu] key on Operation panel.
• "Menu1: Sleep Mode>" is displayed on Operation panel.
b. Press the [>] key on Operation panel to select "Menu2: User Type".
To Next Page
