Before using VJ-1617H OPERATION MANUAL
3-56
NOTE
• Fix the roll media holders by pressing the holders to the printer.
• The procedure for loading the roll media is complete.
• Set the roll media to the printer continuously as shown below.
3.5.5 Setting roll media
3.5.5 Setting roll media
This section explains how to set roll media.
Follow the procedure below to set roll media.
1. Turn the unit ON.
No. Name
1 Roll media holder (Left)
2 Roll media holder (Right)
3 Roll media
4 Fixing lever
1
3
4
3
2
4
31 2
