Appendix VJ-1617H OPERATION MANUAL
8-2
8.1 Product specifications
8.1.1 Printer specifications
Item Specification
Model name VJ-1617H
Printing method On-demand piezo drive system
Drive system Firmware servo/DC motor drive
Media feed system Multipoint pressurizing grid roller system
Media fixing system Pressurization roller down system by manual lever
Media feed/ejection Roll media: Rear feeding/Front ejecting
Thick media: Rear feeding/Front ejecting
Thick media Weight 15kg or less
Maximum length 1200mm
Maximum width 1625mm
Maximum thickness 15mm (warpage of less than 1 mm)
Maximum print width 1615mm
Roll media Outer diameter 150mm or less
Tube diameter 3 inch
Weight 30 kg or less
Maximum width 1625mm
Maximum thickness 0.3mm
Maximum print width 1615mm
Print margin <Thick Media>
Front: Max 5mm, Rear: Max 40mm, Left: 5mm to 25mm, Right: 5mm to
25mm
<Roll Media>
Front: Max 15mm, (For continuous print: 5mm), Rear: 5mm (Maximum end
edge of media is 40mm), Left: 5mm to 25mm, Right: 5mm to 25mm
Media cut system Horizontal manual cut system
Head height adjustment Automatic height adjustment
CPU 64-bit RISC CPU
Memory 384MB
Command MH-RTL (RTL-PASS)
Interface Ethernet (10BASE-T/100BASE-TX)
Ink Supply system Supplied through tubes from independent color cartridges
Ink bag Black, Cyan, Magenta, Yellow: 950ml +5/ -0ml for each color
White: 500ml +5/ -0ml
To Next Page
