Handling the printer VJ-1617H OPERATION MANUAL
4-34
(2) When not interlocking with the printer
1. Turn Link switch of Blower heater to "Manual".
4.5.4 Adjusting Heater output and air volume
The recommended settings are as follows:The air temperature at this condition is 40 to 50C
HEATER adjustment tab: M
Air Pressure adjustment tab: 2
Follow the procedure below to adjust the settings.
1. Change the heater temperature with HEATER adjustment tab of Blower heater.
• OFF: Heater is not turned on.
• L: Heater temperature is set as "Low".
• M: Heater temperature is set as "Medium".
No. Name
1 Link switch
No. Name
1 HEATER adjustment tab
To Next Page
