VJ-1617H OPERATION MANUAL Handling the printer
4-21
4.4 Operating from the operation panel
This section explains various functions that can be operated from the operation panel.
•For names and functions of each key, refer to "2.2.3 Operation panel".
4.4.1 Feeding media
You can feed roll media at a position that you want.
Follow the procedure below to feed media.
1. Confirm that the operation panel is Normal.
2. Make sure that Front media loading lever is lowered (Rear media loading lever is raised).
3. Press the [Forward] key or the [Backwardï‚] key on the operation panel.
• Media is fed forward or backward.
4. Release the [Backwardï‚] key or [Forward] key on the operation panel after feeding media to the
desired position.
4.4.2 Stopping printing operation
If you want to stop printing for some reason, operate as follows.
1. Stop sending printing data from the computer to the printer.
2. Press the [Cancel] key on the operation panel.
To Next Page
