VJ-1617H OPERATION MANUAL Panel setup menu
5-29
5.3.5 Origin menu
Sets the beginning of printing (origin) of the print data.
Set this when you want to print on the margin areas of the media that is already printed on, or when you
want to print on the object that is set on the jig.
• When the Take-up menu is set to "On", the setting value for X (media feeding distance) is between
15 mm and 999.9 mm.
5.3.3 Take-up unit menu
• Depending on the setting value of the side margins, the maxium setting value of Y ’print head
transferring distance) decreases.
5.3.2 Side Margin menu
Setup item Setting Description
Origin <Off> The origin position is not set
On You can set the origin position.
— • [+] key and [-] key: select the menu.
• [Enter] key: enter the origin position.
• [Cancel] key: cancels the setting and shifts to the previous
menu.
•
5.3 Setup menu
To Next Page
