Maintenance VJ-1617H OPERATION MANUAL
6-42
TIP
•For loading roll media, refer to "3.5 Setting media".
•For storing roll media not in use, refer to "4.2.4 Precaution on storing media".
• Roll media replacement is complete.
6.4.4 Replacing the flushing-box sponges
This section explains how to replace the flushing-box sponges.
NOTE
• Make sure to install the flushing-box sponges in the printer.
The flushing-box sponges are an essential part to make printing consistent.
(1) Replacement time
Replace the flushing-box sponges in the following situations.
• When ink clumps have accumulated on the flushing-box sponges beyond the flushing-box frame
(2) Type
TIP
•For types and details of the flushing-box sponge, refer to "8.3 Options/Supply list".
No. Name
1 Ink clump
2 Flushing-box frame
2
1
2
