VJ-1617H OPERATION MANUAL Troubleshooting
7-21
7.3 The media is jammed
When the set media is jammed, follow the procedure below to remove it.
7.3.1 Removing Thick Media
If thick media becomes jammed, contact your local MUTOH dealer.
7.3.2 Removing Roll Media
1. Turn OFF the power of the printer.
3.2.2 Turning the power OFF
2. Open the front cover.
3. Move the print head section from the top of the media to the right.
No. Name
2 Front cover
To Next Page
