VJ-1617H OPERATION MANUAL Before using
3-53
b. In the same way as the front side, fold Media-feed table.
• This completes removing Media-feed table.
• Load the roll media on the printer.
3.5.4 Loading roll media
3.5.4 Loading roll media
This section explains how to load roll media.
Put the roll media in the center.
NOTE
• The following roll media can be attached to the scroller supplied with this unit.
• Outer diameter: 150 mm or less
• Tube diameter: 2 or 3 in.
• Weight: 30 kg or less
• Length: 50 m or less
• Width: 1,625 mm or less
8.1.1 Printer specifications
Follow the procedure below to load roll media.
No. Name
1 Media-feed table
1
2
