Handling the printer VJ-1617H OPERATION MANUAL
4-36
4.6 Using Spectrophotometer
(SPECTROVUE VM-10)
The optional spectrophotometer (SPECTROVUE VM-10) can be attached to print and measure the color
target.
Use SPECTROVUE VM-10-compliant RIP software when performing color calibration or color
profiling for the printer to achieve accurate color printing.
Follow the instructions below.
• Please don’t place the printer where the strong light (for example, sunlight) directly penetrate it.
If strong light penetrates the measuring area, it may impact measurement accuracy.
• When using SPECTROVUE VM-10, the printer must be set as follows.
Make sure to check the settings before use.
• Media thickness detection: On
• Media detection: Height + Width or Height + T&W
5.2.2.7 Media Initial menu
• Take-up unit: OFF
5.3.3 Take-up unit menu
• If the media thickness is changed manually, it may impact measurement accuracy.
• Color measurement may not be accurate when Color target is printed on translucent, colored or
ribbed media.
• When measuring colors, make sure that the color target is dry. If it is not dry enough, the ink may
adhere to the pressurizing rollers of the printer.
• Before using this optional utility, perform test pattern printing.
• The room environment (temperature and humidity) can affect the printed colors. Use the printer
under the conditions specified in "Environmental condition" of "
8.1.1 Printer specifications" in the
Operation Manual. Make sure to leave the media and ink for about two hours in the environment
before use.
1. Connect the printer and computer.
3.8 Connecting the printer to PC
2. Turn the printer ON.
3. Set the media.
3.5 Setting media
4. Set up the media type.
3.5.6 Setting media type
• Once media type setting and media initial operation are complete, "Ready to Print" is displayed
on Operation Panel.
