2.2.3 Operation panel
There are two Operation panels on this printer: Printer operation panel and Blower heater operation
panel.
Used for setting operation conditions, display of printer status and various functions.
Names of each operation key (Switch) and status display along with the functions are explained.
TIP
•Refer to the following for details regarding the operation method of the operation panel.
•When performing menu setting from the printer operation panel:
4.3 Menu setups on the operation panel
•When performing various operations in the printer operation panel: 4.4 Operating from the operation panel
•When performing various operations in the Blower heater operation panel: 4.5 Using Blower heater
2.2.3.1 Printer operation panel
8, 9
3
15
17
16
6
5
11
12
1
13
14
10
27
4
