• The operation keys are assigned with different functions and names depending on printer status
(Normal or Setup menu display).
For details about printer status, refer to "
2.3 Printer status".
No. Name Normal Setup menu display
1 [Menu] key Shifts to the Setup menu. Shifts from Setup menu display to Normal.
2 [Enter] key Restarts printing when the printing is
suspended.
• Select the menu to be set, and shifts to the
next hierarchy.
• The setting is determined and saved.
[Long Feed] key Feeds a specified amount of media when
pressed for more than two seconds.
—
3 [Pause] key Pauses printing. —
[Cancel] key Press and hold this key for more than two
seconds to do the following operations:
• When printing:
Forcefully terminates printing and deletes
one file of the remaining data.
• When receiving or analyzing:
Deletes data that are already received and
analyzed, and delete the next data.
• Returns to the previous menu hierarchy.
Changes made in the setting are discarded.
• Shifts from Setup menu display to Normal.
4 [<] key — Changes the set value.
[Nozzle Check] key Press and hold this key for two seconds or
more to perform Nozzle Check printing.
—
5 [>] key Sets Cleaning Mode.
• The lamp of Cleaning Mode that you set
lights up in green.
• Down the menu level in the directory tree.
• Changes the set value.
6[Backwardï‚] key Media is fed in the reverse direction. —
[+] key — • Changes to the previous item in the
displayed menu.
• The setting is changed to the forward
direction.
• The numeric value is increased during
numerical input.
7[Forward] key Media is fed in the forward direction. —
[–] key — • Changes to the previous item in the
displayed setting.
• The setting is changed to the reverse
direction.
• The numeric value is decreased during
numerical input.
8 [Power] key Turns the printer ON and OFF. Turns the printer ON and OFF.
