VJ-1617H OPERATION MANUAL Appendix
8-3
Environmental
condition
Operating condition Temperature: 20 °C to 28 °C
Humidity: 40% to 60%, No condensation
Printing accuracy
coverage
Temperature: 22 °C to 28 °C
Humidity: 40% to 60%, No condensation
Change rate Temperature: within 2 °C per one hour
Humidity: within 5 % per one hour
Archiving condition
(Ink not filled)
Temperature: –20ºC to 60ºC
Humidity: 20% to 80%, No condensation
Storage life: six months
Archiving condition
(Ink filled)
Temperature: –10ºC to 30ºC
Humidity: 20% to 80%, No condensation
Storage life: 30 days (Perform the maintenance operation written in the
operation manual.)
Power Rated voltage MAIN AC 100V240V
HEATER1 AC100-120V/200-240V
HEATER2 AC100-120V/200-240V
Range of voltage
input
MAIN 100V-240V ± 10%
HEATER1 AC100-120V ± 10% / 200-240V ± 10%
HEATER2 AC100-120V ± 10% / 200-240V ± 10%
Power consumption Printing (AC 100 V to 120 V ± 10%)
MAIN: Max. 300W
HEATER1: Max. 1000 W
HEATER2: Max. 1100 W
(200 V to 240 V ± 10%)
MAIN: Max. 300W
HEATER1: Max. 2200 W
HEATER2: Max. 0 W
At warming up (AC 100 V to 120 V ± 10%)
MAIN: Max. 40W
HEATER1: Max. 1200 W
HEATER2: Max. 1200 W
(200 V to 240 V ± 10%)
MAIN: Max. 40W
HEATER1: Max. 2400 W
HEATER2: Max. 0 W
Standby MAIN: 40 W or less (When the idle heat is turned OFF)
Heater1: 25 W or less (When the idle heat is turned OFF)
Heater2: 0.4 W or less (When the idle heat is turned OFF)
Reference for warming up time of the heaters In the recommended setting (Heater: M, Air volume: 2), environmental
temperature of 25ï‚°C : 10 minutes
Environmental temperature 20ï‚°C: 15 minutes
Outer diameter Height 1302mm (including the stand)
1416mm (Dedicated stand, High-capacity pack adapter, and Ink pack
installed)
Width 2698mm
Depth 2486mm (including media-feed table)
818mm (main unit only)
931mm (Main body only, High-capacity pack adapter and Ink pack installed)
Weight Approx. 200.5kg (including the stand)
Item Specification
