VJ-1617H OPERATION MANUAL Handling the printer
4-43
18. Press [Enter].
• "Wait for a while…" is displayed on Operation Panel.
• "Remove white plate then close left maintenance cover." is displayed on Operation Panel.
NOTE
Without pressing "Enter", it is able to move to the next procedure. Move to step 19.
19. Remove White reference plate from the plate mounting position, turn it over so that the black side is
facing up to install it to the original position.
No. Name
1 Connector cap
2Tabs
3Print Head
4 Connector
1
2
2
41 3
